There are three reasons you should be confident about measuring you own pool:

  1. You’re invested in the outcome! That’s right, who’s going to take more time to get it right, you or a summer student working for minimum wage.  We think it’s you!
  2. Pool Fits provides great tools, like individual measuring sheets for each aboveground pool shape
  3. You’ve got us! We’re available real-time during store hours to Chat on-line or Talk on the phone to answer questions:

Call Toll-Free: 1-877-325-3487 (FITS)

Tools Required to measure an Onground pool

  • Minimum of 2 People – Ideally 3 People (which allows someone to record measurements while the others work the tapes)
  • 1 – 50 Foot Tape Measure
  • Pool Fits On Ground Round Measurement Sheet
  • Black Ink Pen
  • Chalk

How to Measure- On Ground Rectangle Pool

Rectangle

  • If the corners of your Rectangle Pool are Radius or Cut-Off (Diagonal) square off the corners using chalk.
  • Take Measurements, both Width and Length to the Square Corners as shown on the diagram.
  • Take Measurements for the Diagonals as shown on the diagram in case the pool is out of square.

Tip:  If your ordering a ‘custom’ onground liner, always use a Pool Fits Rectangle On Ground Liner Measurement Form!

Tip:  If your Onground Rectangle Pool has a ‘hopper’ or ‘deep-end’ refer to Pool Fits Manufacturer’s Standard Specification to verify the bottom configuration measurements.

Rectangle Onground Corner Types

  • Kayak & Fanta Sea Onground Pools  = Square Corners
  • Wilkes Onground Pools = 8-1/2″ Cut-Off (Diagaonal) Corners
  • Olympic Onground Pools = 6″ Radius Corner

Tip:  If you need help determining what type of Corners on your Onground Rectangle Pool click on the following link: Onground Liner Corners Knowledge



How to Measure On Ground Rectangle
How to Measure Onground Rectangle Diagonals

The arrow lines above represent the required measurement to determine the size of an Rectangle Ongound Pool

How to Measure- On Ground Octagon Pool

Octagon

  • Octagon Shape Pools have 8 equally sized sides
  • To properly determine the size of your Octagon On Ground Pool you’ll need to take 3 measurements:



    • Panel Length
    • Width
    • Diagonal



Tip:  If your ordering a ‘custom’ Octagon onground liner, always use a Pool Fits Octagon On Ground Liner Measurement Form!

Tip:  If your Onground Octagon Pool has a ‘hopper’ or ‘deep-end’ refer to Pool Fits Manufacturer’s Standard Specification to verify the bottom configuration measurements.





Octagon Onground Pool How to Measure

The arrow lines above represent the required measurement to determine the size of an Octogon Ongound Pool

How to Measure- On Ground Grecian | Emerald | Octagonal Pool





Grecian | Emerald | Emerald II | Octagonal





  • Take Measurements, both Width and Length as shown on the diagram



  • Take the pool straight wall measurements as shown the diagram



  • Take Measurements for the Diagonals as shown on the diagram in case the pool is out of square.





Tip:  If your ordering a ‘custom’ onground liner, always use a Pool Fits Grecian / Emerald On Ground Liner Measurement Form!



Tip:  If your Onground Grecian / Emerald Pool has a ‘hopper’ or ‘deep-end’ refer to Pool Fits Manufacturer’s Standard Specification to verify the bottom configuration measurements.

Onground Emerald How to Measure
Emerald Onground - How to
Onground Emerald How to Measure Diagonals

The arrow lines above represent the required measurement to determine the size of an Grecian or Emerald Ongound Pool

How to Measure- On Ground Kidney Pool

Kidney

  • Measure the Width of the pool at 4 locations as shown



  • Measure the Length of the pool at 1 location as shown



  • Measure all Panel & Straight Wall Lengths as shown



  • Measure 5 Diagonals as shown



Tip:  If your ordering a ‘custom’ Kidney onground liner, always use a Pool Fits Kidney On Ground Liner Measurement Form!

Tip:  If your Onground Kidney Pool has a ‘hopper’ or ‘deep-end’ refer to Pool Fits Manufacturer’s Standard Specification to verify the bottom configuration measurements.

Tip:  Be certain to identify properly the ‘hand’ of your pool:

  • Right Hand
  • Left Hand
Onground Kidney - How to
Onground Kidney Pool How to Measure

The arrow lines above represent the required measurement to determine the size of an Kidney Ongound Pool

How to Measure- On Ground Round Pool

Round

  • The Diameter of a Round Pool is the size of the pool and the pool liner required.
  • The Diameter is the measurement across the pool from side to side that goes through the very center of the pool.
    • The easiest way to determine if the tape measure is going through the center of the pool is ensure that you are measuring the ‘widest width’ of the pool.  This is best accomplished by taking several measurements until you can confirm several times that the measurement is in fact the widest possible measurement.
  • The best ‘cross check’ that the Diameter measurement is correct is to measure the perimeter or the circumference of the pool.  This can be done by measuring the distance around the top of the pool in 1′ increments:
  • Example: 24′ Round
    • 75 – 1′ increments + 4″
    • Total Wall Length =75′-4″ or 75.34′
    • Cross Check 75.33 / 3.1416 = 23.98′ or 24′ Diameter

Tip:  If your ordering a ‘custom’ onground liner, always use a Pool Fits Round On Ground Liner Measurement Form!

How to Measure On Ground Round

The arrow line above represents the required measurement to determine the diameter or size of a Round Onground Pool

How to Measure- On Ground Oval Pool

Oval

  • The Length and Width of an Oval Pool are the size of the pool and the pool liner required.
  • The Length is the measurement between the two round ends of the pool through the very center of the pool.
    • The easiest way to determine if the tape measure is going through the center of the pool is ensure that you are measuring the ‘longest length’ of the pool.  This is best accomplished by taking several measurements until you can confirm several times that the measurement is in fact the longest possible measurement.
  • The Width is the measurement between the two straight walls of the pool
    • This measurement should be taken at the beginning and end of the straight wall of the pool and should be the same measurement in both locations.  If this measurement varies by an inch or two it will have not affect on the fit of the pool liner.

Tip:  If your ordering a ‘custom’ onground liner, always use a Pool Fits Oval ON Ground Liner Measurement Form!







How to Measure On Ground Oval Pool

The arrow lines above represent the required measurement to determine the size of an Oval Ongound Pool

How to Measure- On Ground Pool Wall Height

Wall Height



  • Check the Wall Height in several places around the pool.  Use the shortest of these measurements.



  • Onground Wall Height Guide:

                   Brand               Typ Pool Wall Height      Typ Finished Wall Height

    • Champlain                       42″                                           40″
    • Driftwood                        42″                                           40″
    • Fanta Sea                         48″                                           46″
    • Kayak                                 48″                                           46″
    • Olympic                            48″                                           46″
    • Wilkes                                48″                                           46″
    • Esther Williams            48″                                           46″



Tip:  Use the chart above as a guide and always verify the actual wall height measurements!

Onground Pool Wall Height



How to Measure Onground Wall Height

Wall Heights may vary due to the pool bottom thickness and height.  Always measure from the Bead Receiver to the finished pool floor to accurately measure the Onground Pool Wall Height.
